Part #49118
MFG #49118
Product Description
1/8" MPT, 0 to 120 PSI, 3-1/8" Diameter Blue Dial, 1% Accuracy, Bottom Connection, Rugged Steel Case, Copper Alloy Bourdon Tube, R-32/R-454B/R-410A, Class 1, Heavy Duty, Fahrenheit, Dry Manifold Compound Gauge
Part #49118
MFG #49118
Product Description
1/8" MPT, 0 to 120 PSI, 3-1/8" Diameter Blue Dial, 1% Accuracy, Bottom Connection, Rugged Steel Case, Copper Alloy Bourdon Tube, R-32/R-454B/R-410A, Class 1, Heavy Duty, Fahrenheit, Dry Manifold Compound Gauge
- Large 3-1/8" Gauges are Housed in a Blue Steel Case with Front Recalibrator Screw; High Visibility Colored Temperature Scales are Easy to Read through the Full View Polycarbonate Crystal; Flutterless™ Technology with Brass Surge Protector to Minimize Needle Pulsation; A2L Compatible; Made in USA
- Dry Manifold Compound Gauge; Pressure Gauge Type Class 1, Heavy Duty, Fahrenheit; Minimum Pressure 30 Inch Hg Vacuum/0 PSI; Maximum Pressure 120 PSI; Display Type Dial; Enclosure Material Rugged Steel Case; End Connection 1/8 Inch Male Threaded; Connection Location Bottom; Sensor Element Copper Alloy Bourdon Tube; Dial Diameter 3-1/8 Inch; Dial Color Blue; Accuracy 1 Percent; Application R-32/R-454B/R-410A Refrigerant; Material Polycarbonate (Crystal), Brass (Movement/Surge Protector); Includes Front Recalibrator Screw
- Brand
Yellow Jacket
Accuracy1 Percent
Connection LocationBottom
Dial ColorBlue
Dial Diameter3-1/8 Inch
Display TypeDial
Enclosure MaterialRugged Steel Case
End Connection1/8 Inch Male Threaded
Maximum Pressure120 PSI
Minimum Pressure30 Inch Hg Vacuum/0 PSI
Pressure Gauge TypeClass 1, Heavy Duty, Fahrenheit
Sensor ElementCopper Alloy Bourdon Tube
